High Level Bulk Bottle or CAN Depalletizer
Product overview
This depalletizer is used to unload the empty bottles from the full stack automatically, which can improve the site working condition and production efficiency to satisfy customer’s production and packaging requirements.
This depalletizer is used to unload the empty bottles from the full stack automatically, which can improve the site working conditions and production efficiency to satisfy customers’ production and packaging requirements.
Workflow:
Forklift transport the complete stack of empty bottles to the full pallet conveyor of this depalletizer, then the conveyor transport the full stack to the main lifting platform, the lifting platform lift up the full stack layer by layer; The interlayer collecting structure suck the interlayer and move it out of the stack, after that the interlayer collecting mechanism will collect the interlayers and lift it down to conveyor out of the machine when the interlayers is stored as one stack; the clamp of bottle grips the whole layer of bottles and moves them to empty bottle conveyors, repeat these actions until the all the layers are moved to the conveyor, then the lifting platform will down and output the empty pallet to the pallet magazine.
Technical Parameter:
| Stack Speed | 400/600/800 cans per minute |
| Max. carrying capacity /layer | 150Kg |
| Max. carrying capacity /pallet | Max 1500kG |
| Max. stack height | 1800mm (Customized) |
| Installation Power | 18KW |
| Air Pressure | ≥0.6MPa |
| Power | 380V.50Hz , three-phase +ground wire |
| Consumption of the Air | 800L/Min |
| Size of the Pallet | According to customer requirement |
